Basic Vapors Breakthrough Indicator Inline
Indicator for Basic Vapors
Item No. 605
Product Features
Minimum detectable limit: 4ppm•min
Color Change: Orange to green to blue
Inlet & outlet dimensions: ¾” Male NPT
Service life: 14 months
$77.09
Basic Vapors Breakthrough Indicator-Inline is reliable and cost effective. The indicator is easily connected in-line with ¾” male, male NPT inlet and outlet. It is sensitive to acid gases and vapors. You can observe the bright vibrant color change from all directions.
PN 605
Product Specifications
a | Weight: | 28g (1.0oz) |
b | Dimensions: | 89.9mm (3.5in), diameter 24.5mm (1.0in) |
c | Inlet and outlet dimensions: | ¾” MNPT |
d | Operating temperature: | -20oC to 55oC (-4oF to 131oF) |
e | Operating humidity: | 5% RH to 85%RH |
f | Minimum detectable limit: | 4ppm•min at 30 cm/sec face velocity |
g | Color change: | Orange to green to blue |
h | Storage temperature: | 4oC to 25oC, (39oF to 77oF) |
i | Shelf life: | 14 months at 4oC to 25oC, (39oF to 77oF) |
j | Service life: | 14 months |
Refill Kit
THE BASIC VPORS BTI INLINE CAN BE REUSED BY REPLACING THE EXHAUSTED BASIC VPORS INDICATOR WITH FRESH BASIC VPORS INDICATOR ASSEMBLY.
The Basic Vapors BTI Inline Refill Kit Item No.605-5000 Includes:
1- One Basic Vapors Indicator Assembly (Item No. 605-1600)
2- Two Porous Plugs (Item No. 617-1400)
Miniature-Hook Pick (Item No. 431-9100) Optional
Please call us (1-855-243-6837) or email us
Related Products
Basic Vapors BTI. Drum type filter change indicator
Basic Vapors BTIS. Filter change indicator for ductless hood and fume extractor filters
Useful Link
Basic Vapors Breakthrough Indicator-Inline
