Ammonia & hydrogen sulfide Filter with end of service life indicator for chemical processes and reactor vents

Ammonia & Hydrogen sulfide DG Filter with ESLI

Ammonia & hydrogen sulfide Filter with end of service life indicator

Item No. 7406

Dimensions: Length = 89.9mm (3.5”), diameter = 24.5mm (1”), Inlet & outlet = ¾” Male NP

$103.67

Ammonia & Hydrogen Sulfide Filter ESLI – PN 7406
The Ammonia & Hydrogen Sulfide DG Filter with end of service life indicator (ESLI) is an efficient and reliable filter most suited for chemical processes and reactor vents. The ESLI allows the user to safely use filter without the possibility of toxic gases and vapors breakthrough to the surrounding environment. The ESLI changes color when the filter is about 75% to 80% consumed, allowing 20 to 25% of sorption media as safety buffer.

Filter Specifications:
Filter with End-of-Services Life Indicator (ESLI)
Length = 3.5”, diameter = 1”, Inlet & outlet = ¾” female NPT
Up to 15g. of special blends sorption media
Suitable for Chemical Processes and Reactors Vents

Filter & ESLI Specifications:

a Weight: 34g (1.6oz)
b Dimensions: 89.9mm (3.5in), diameter 24.5mm (1.0in)
c Inlet & outlet dimensions: ¾” MNPT
d Operating temperature: -20oC to 40oC (-4oF to 104oF)
e Operating humidity: 5% RH to 85%RH
f Minimum detectable limit: Ammonia 10ppm●hr

Hydrogen Sulfide 1ppm●min

g Color change: Ammonia: light blue to dark blue

Hydrogen Sulfide: Light blue to black

h Storage temperature: 4oC to 25oC, (39oF to 77oF)
i Shelf life: 2 years at 4oC to 25oC, (39oF to 77oF)
Service life: 2 years
